CT/C 200 deep-rib roofing and wall sheet
CT/C 200 is a deep-rib steel cladding sheet with six 38 mm ribs and a 915 mm cover width. It is used on roofs but mostly on walls, fitted with the ribs facing in to give a strong vertical line when re-cladding a facade.
A1[In stock IE?]
Thicknessup to 1.0 mm steel
Cover width915 mm
MaterialSteel
- Nationwide delivery
- No minimum order
- Samples available
- Lead time depends on stock
About the CT/C 200 steel cladding sheet
It is supplied up to 1.0 mm thick, weighing 5.3 kg/m² at 0.5 mm. As steel it is A1 for reaction to fire and BRoof(cwft) on roofs.
Specification
Size and profile
- Cover width
- 915 mm
- Length
- Made to length from continuous production.
- Steel gauge
- up to 1.0 mm
- Ribs / pitch / height
- 6 ribs · 183 mm pitch · 38 mm high
- Rib width / base
- 15 mm / 28 mm
- Side overlap
- 1 rib(s)
Core and joint
- Material
- Single-skin profiled steel sheet
- Manufacturer
- Isolpack S.p.A., Italy
Facings and coatings
- Facings
- Pre-painted or plasticised galvanised steel · Aluzinc · Stainless steel · Natural, pre-painted or embossed aluminium
- Coatings
- Polyester, Superpolyester (HD), PVDF, polyurethane PUR/PA, 15–55 µm. Other films and food-safe coatings on request.
Non-standard thicknesses on request, subject to minimum quantities.
Weight by gauge
| Steel gauge | kg/m² |
|---|---|
| 0.5 mm | 5.3 |
| 0.6 mm | 6.4 |
| 0.7 mm | 7.4 |
| 0.8 mm | 8.5 |
| 1.0 mm | 10.6 |
Fire certification
| Test | Class | Thicknesses |
|---|---|---|
| Reaction to fire EN 13501-1 · Steel | A1 | all |
| External fire EN 13501-5 · Steel | BRoof(cwft) | all |
Classes are per core and thickness and must be specified at order. The whole range is CE marked with EPD type III (EN ISO 14025) declarations, from an ISO 9001, 14001 and 45001 certified manufacturer.
Use it for
IndustryCommercialAgricultureInfrastructureResidential
