Delta 3
Insulated roof panel · 3 trapezoidal ribs, 40 mm high, 200 mm module · 30–120 mm · PUR / PIR
B-s2,d0Solar-ready
View Delta 3 Insulated roof sheeting & roof panels
Insulated roof sheeting from 10 to 150 mm with a PIR or PUR core, made to the length of your roof and delivered anywhere in Ireland. Twelve roof panel profiles: double-skin sandwich panels, felt-backed single-skin panels for concrete decks, and flat-roof deck panels.
12profiles
0.15W/m²K at 150 mm
BRoof(t3)solar-ready options
All insulated roof sheeting products
Delta 5
Insulated roof panel · 5 trapezoidal ribs · 30–150 mm · PUR / PIR
B-s1,d0REI30Solar-ready
View Delta 5
Isometal 4G
Insulated roof panel · 4 trapezoidal ribs · 30–50 mm · PUR / PIR
B-s2,d0
View Isometal 4G
Dryclamp
Ventilated roof panel system · trapezoidal rib with patented clamp fixing (no through-drilling) · 30–140 mm · PUR / PIR
B-s1,d0REI30Solar-ready
View Dryclamp
Techtum
Roof panel for precast concrete buildings · trapezoidal longitudinal section (truss-like), flat soffit · variable 40–130 mm (trapezoidal longitudinal section) · PUR / PIR
Solar-ready
View Techtum
Kappa 3
Single-skin insulated roof panel · 3 trapezoidal ribs · 20–120 mm · PUR / PIR
Agri version
View Kappa 3
Kappa 5
Single-skin insulated roof panel · 5 trapezoidal ribs · 20–120 mm · PUR / PIR
BRoof(t3)Solar-readyAgri version
View Kappa 5
Isogrek H28
Anti-condensation insulated sheet · 9 trapezoidal ribs, 28 mm high (H28 profile) · 10 mm · PUR 60 kg/m³
BRoof(t3)Solar-readyCurvable
View Isogrek H28
Kappa 3 Deck
Insulated flat roof deck panel · 3 trapezoidal ribs facing down · 30–120 mm · PUR / PIR
View Kappa 3 Deck
Kappa 5 Deck
Insulated flat roof deck panel · 5 trapezoidal ribs facing down · 30–120 mm · PUR / PIR
View Kappa 5 Deck
Sigma
Insulated flat roof deck panel · 5 trapezoidal ribs facing down, 710 mm cover width · 30–100 mm · PUR / PIR
View SigmaCompare the range
Declared values from manufacturer datasheets to EN 14509 and EN 13501. A dash means no rating is published.
| Product | Type | Core | Thickness | U @ 100 mm | Reaction to fire | Fire resistance | External fire |
|---|---|---|---|---|---|---|---|
| Delta 3 | Insulated roof panel | PUR / PIR | 30–120 mm | 0.22 | B-s2,d0 | – | – |
| Delta 5 | Insulated roof panel | PUR / PIR | 30–150 mm | 0.22 | B-s1,d0 | REI30 | BRoof(t3) |
| Isometal 4G | Insulated roof panel | PUR / PIR | 30–50 mm | 0.43 at 50 mm | B-s2,d0 | – | – |
| Dryclamp | Ventilated roof panel system | PUR / PIR | 30–140 mm | 0.22 | B-s1,d0 | REI30 | BRoof(t3) |
| Techtum | Roof panel for precast concrete buildings | PUR / PIR | variable 40–130 mm (trapezoidal longitudinal section) | – | – | – | – |
| Supercoppo | Tile-effect insulated roof panel | PUR / PIR | 40–100 mm | 0.20 | B-s2,d0 | – | BRoof(t3) |
| Kappa 3 | Single-skin insulated roof panel | PUR / PIR | 20–120 mm | 0.22 | – | – | – |
| Kappa 5 | Single-skin insulated roof panel | PUR / PIR | 20–120 mm | 0.22 | – | – | BRoof(t3) |
| Isogrek H28 | Anti-condensation insulated sheet | PUR 60 kg/m³ | 10 mm | – | – | – | BRoof(t3) |
| Kappa 3 Deck | Insulated flat roof deck panel | PUR / PIR | 30–120 mm | 0.22 | – | – | – |
| Kappa 5 Deck | Insulated flat roof deck panel | PUR / PIR | 30–120 mm | 0.22 | – | – | – |
| Sigma | Insulated flat roof deck panel | PUR / PIR | 30–100 mm | 0.22 | – | – | – |
Which one do I need?
Not sure? Send us the span, the use and the county and we will spec it. No charge.
Get a quote- Cattle or sheep shed, 20 m+ spans
- Delta 5 at 40–60 mm, or Isogrek H28 where you only need to stop drips
- Heated workshop or warehouse
- Delta 5 at 80–100 mm (0.27–0.22 W/m²K); B-s1,d0 from 100 mm
- Roof that will carry solar panels
- Dryclamp: PV clamps to the rib, no holes in the roof, BRoof(t3)
- Concrete roof deck or dairy parlour
- Kappa 3 or 5, felt-backed; Agri version with aluminium or fibreglass underside
- House or old building that needs a tiled look
- Supercoppo tile-effect insulated panel
Facings and coatings
Pre-painted galvanised steel as standard; Aluzinc, stainless steel, aluminium and copper on request. Coatings: polyester, Superpolyester HD, PVDF, PUR/PA.
Certifications on this range
Reaction to fire (EN 13501-1), fire resistance (EN 13501-2), external fire (EN 13501-5), EPD type III and CE marking. Classes depend on core and thickness and are confirmed at order.
Full certification tablesInsulated roof sheeting & roof panels questions
What is the difference between insulated roof sheeting and roof panels?
Nothing, in practice. Irish roofers say "insulated roof sheeting" or "insulated sheets"; manufacturers say "sandwich panels" or "insulated roof panels". Both mean a steel outer skin, an insulating core and an inner skin made as one piece.
What thickness of insulated roof panel do I need in Ireland?
It depends on whether the building is heated, what is under the roof and the purlin spacing. The U-value tables on each product page show what every thickness achieves; contact us and we will recommend one for your job.
Can I fit solar panels on an insulated roof?
Yes. Delta 5, Kappa 5, Supercoppo and Isogrek H28 are certified BRoof(t3) for external fire, and the Dryclamp system lets PV mount to the rib without drilling the panel.
How long can a panel be?
Panels come off a continuous line, so length is set by transport and handling rather than the product. Tell us the roof and we will advise.
